Double flutes 3D engraving bits

适用：密度板，压克力，PVC等3D雕刻和倒角，双刃设计，同心度非常好，刃口锋利，底部不留屑。
Good for: 3D engraving and chamfer angle on Acrylic, MDF, and PVC. Excellent concentricity, sharp cutting edge, non-stick in the bottom
订购产品须在编号前加材质编号:N ,A					Material: SOLID CARBIDE,硬质合金（钨钢）
Products must be ordered by adding the Materials Code Number like N, A .					参考价格：人民币 PRICE(RMB)
编号	刃径	全角	刀尖	柄径	N系列	A系列
PART NO	CED	A	TIP	SHK	N series	A series
2V61045	10	45°	0.2	6	*******	*******
2V61060	10	60°	0.2	6	*******	*******
2V61090	10	90°	0.2	6	*******	*******
2V610120	10	120°	0.2	6	*******	*******
2V610150	10	150°	0.2	6	*******	*******
2V61660	16	60°	0.2	6	*******	*******
2V61690	16	90°	0.2	6	*******	*******
2V616120	16	120°	0.2	6	*******	*******
2V616150	16	150°	0.2	6	*******	*******
2V62260	22	60°	0.2	6	*******	*******
2V62290	22	90°	0.2	6	*******	*******
2V6229020	22	90°	2.0	6	*******	*******
2V622120	22	120°	0.2	6	*******	*******
2V622135	22	135°	0.2	6	*******	*******
2V622150	22	150°	0.2	6	*******	*******
2V63260	32	60°	0.2	6	*******	*******
2V63290	32	90°	0.2	6	*******	*******
2V6329020	32	90°	2.0	6	*******	*******
2V632110	32	110°	0.2	6	*******	*******
2V632120	32	120°	0.2	6	*******	*******
2V632130	32	130°	0.2	6	*******	*******
2V632135	32	135°	0.2	6	*******	*******
2V632140	32	140°	0.2	6	*******	*******
2V632150	32	150°	0.2	6	*******	*******
2V12.2290	22	90°	0.2	12.7	*******	*******
2V12.22120	22	120°	0.2	12.7	*******	*******
2V12.22150	22	150°	0.2	12.7	*******	*******
2V12.3290	32	90°	0.2	12.7	*******	*******
2V12.32120	32	120°	0.2	12.7	*******	*******
2V12.32150	32	150°	0.2	12.7	*******	*******
2V12.4590	45	90°	0.2	12.7	*******	*******
2V12.45120	45	120°	0.2	12.7	*******	*******
2V202290	22	90°	0.2	20	*******	*******
2V2022120	22	120°	0.2	20	*******	*******
2V203290	32	90°	0.2	20	*******	*******
2V2032120	32	120°	0.2	20	*******	*******
2V204590	45	90°	0.2	20	*******	*******
2V2045120	45	120°	0.2	20	*******	*******
